Vacuum press wood dryer
![vacuum press wood kiln working theory](https://abtmac.com/wp-content/uploads/vacuum-kiln-theory-1024x576.jpg)
Our advanced vacuum press wood dryer revolutionizes wood drying by placing the wood in a sealed container and applying sub-atmospheric pressure. This accelerates the movement of moisture from the wood’s interior to its surface, ensuring even drying. The wood is continuously heated while the vacuum system removes air from the chamber, significantly lowering the vaporization temperature. This allows the wood to dry at reduced temperatures, effectively preventing issues such as cracking and deformation.
Experience unparalleled efficiency: a 30mm thick board dries in just 24 hours, a 50mm thick board in 72 hours, and 60-70mm thick boards in approximately 96 hours. This is up to 5 – 15 times faster than conventional drying methods. Choose our vacuum kiln technology for superior, rapid, and reliable wood drying results.
Model | VP-5-ABT | VP-11-ABT | VP-15-ABT | VP-22-ABT |
---|---|---|---|---|
Stacking Capacity (based on 50mm thick wood space) | 5cbm | 11cbm | 15cbm | 22cbm |
Stacking Size | 3200*1400 | 7500*1250 | 8100*1600 | 8200×2000 |
Inner Size | 4600*1560*1755 | 8900*1410*1820 | 9500*1760*1820 | 9500x2160x2080mm |
Outter Size | 4900*2130*2125 | 9300*1780*2250 | 10000*2210*2330 | 10000×2610 x2590mm |
Loading & Unloading | Motor drived rail cart | |||
Qty of Heating Plates | 24 | 25 | 25+2 | 29 |
Heating Medium | Steam | |||
Power Required | 12kw | 14kw | 17kw | 22kw |
Main Body | Stainless steel inside; square steel reinforcement outside; cylinder lifting device above; end-opening kiln door; kiln door sealing and locking system. | |||
Lift System | Gantry crane and accessories. | |||
Control System | Fully automatic controller (touch screen); temperature sensor module system; pressure sensor module system; moisture content detection system; power distribution cabinet and its electrical components. | |||
Heating & Circulating System | Heater; Aluminum alloy heating plate; Circulation pump; Piping; Valve, etc. | |||
Vacuum System | Vacuum pump and supporting accessories. | |||
Cooling System | Large cooling fan; radiator. | |||
Automatic Loading & Discharging System | Loading trolley; electric transportation control device. | |||
Automatic Drain System | Motorized valves; piping and draining devices. |
All vacuum press wood dryers can be custom made as per customer’s requirement.
